High Speed Automated E-commerce Cross Belt Sorter Accurate Efficient Streamlined

High Speed Automated E-commerce Cross Belt Sorter Accurate Efficient Streamlined

Brand Name:	Realkey
Model Number:	RKSORT-CBS
MOQ:	1 unit
Price:	Customized products
Payment Terms:	L/C,T/T,D/P

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/EAC/UL/ISO

Custom Order:

OEM/ODM:

Fatory:

Direct Factory With Own Exporting Platform

Feature:

Flexible Sorting Of Multiple Sizes And Directions

Special Feature:

12000 To 15000 Tickets/hour

Speed:

Adjustable Within The Range Of 2.0-2.5m/S

Warranty:

1 Year

Dimension(L*W*H):

Customization

Recognition Rate:

99.99%

Certification:

CE/ROHS/ISO9001/ECM

Applicable Industries:

Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction Works , Other, Logistics Transportation Sorting

Material Feature:

Fire Resistant

Aftersales Support:

Install Instruction, Video Support, On-line Guidance

After-sales Service Provided:

Online Support Video Technical Support

Trademark:

ODM & OEM

HS Code:

8479894000

Bar-code Reading:

>99.99%

Noise:

<72BD

Highlight:

Efficient Cross Belt Sorter

Streamlined Cross Belt Sorter

Automated E-commerce Cross Belt Sorter

Product Description

High-Speed Automated E-commerce Cross Belt Sorter Accurate Efficient Streamlined

The circular cross belt sorter uses the motor to drive the car queue connected head and tail to move at high speed along the circular track,Each trolley has an independent power driven conveyor belt,The conveyor belt can move vertically with the trolley running direction.The goods with barcode are led into the trolley from the package supply platform,Locate the destination after scanning by the identification system,Trolley belt rotates when arriving at the designated place,Unload the goods to the unloading port to complete the sorting action.The cross belt sorter has efficient and accurate processing capacity,Especially applicable to express logistics, e-commerce and distribution centers.

High Speed Automated E-commerce Cross Belt Sorter Accurate Efficient Streamlined 0

Technical Parameters

Equipment Name	Circular Cross Belt Sorter	Linear Cross Belt Sorter	Linear Cross Belt Sorter
Model	CBS-600C	CBS-500L	CBS-300L
Sorted Items	Various parcels, cartons, clothing, books, etc.
Cart Pitch	600mm	500mm	300mm
Sorting Accuracy	99.99%
Sorting Efficiency	22,000 pcs/hour	6,000 pcs/hour	8,000 pcs/hour
Feeding Method	Manual loading /Automatic loading from feeding station
Sorted Goods Size	MAX: 700×600×500mm MIN: 150×150×8mm
Sorted Goods Size	MAX: 700×600×500mm MIN: 150×150×8mm
Scanning Method	Top scan / Three-phase five-sided scan / Six-sided scan
Sorted Goods Weight	0.03kg ≤ W ≤ 20kg	0.03kg ≤ W ≤ 20kg	0.1kg ≤ W ≤ 30kg
Operating Speed	2.0m/s	1.5m/s	1.5m/s
Operating Noise	≤72dB(A)

High Speed Automated E-commerce Cross Belt Sorter Accurate Efficient Streamlined 1

Features:
1,High efficiency vision plan
2,High accuracy data collection
3,Small space occupancy
4,High output 8000-10000 parcels per hour
5,Wide ranges of items sortable
6,Reduces labor resources
7,Easy maintenance
8,Compact structure
9,Open for adding more sorting ports/expandable
10,High performance drive system options
11,Modular design with flexible belt

High Speed Automated E-commerce Cross Belt Sorter Accurate Efficient Streamlined 2
