Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments

Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments

Brand Name: Realkey
Model Number: RKSORT-CBS
MOQ: 1 unit
Price: Customized products
Payment Terms: L/C,T/T,D/P
Detail Information
Place of Origin:
China
Certification:
CE/EAC/UL/ISO
Custom Order:
Accept
OEM/ODM:
Accept
Fatory:
Direct Factory With Own Exporting Platform
Feature:
Flexible Sorting Of Multiple Sizes And Directions
Special Feature:
12000 To 15000 Tickets/hour
Speed:
Adjustable Within The Range Of 2.0-2.5m/S
Warranty:
1 Year
Dimension(L*W*H):
Customization
Highlight:

Intelligent Loop Cross Belt Sorter

,

Real Time Sorting Parcel Sorter

,

Adjustments Cross Belt Parcel Sorter

Product Description
Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments
Product Specifications
Custom Order Accept
OEM/ODM Accept
Factory Direct Factory With Own Exporting Platform
Feature Flexible sorting of multiple sizes and directions
Special Feature 12000 to 15000 tickets/hour
Speed Adjustable within the range of 2.0-2.5m/S
Warranty 1 Year
Dimension(L*W*H) Customization
Advanced Parcel Sorting Solution

The Realkey Cross Belt Sorter is an advanced system engineered for efficient sorting of parcels and cartons. It integrates tracks, carts, perpendicular belts, recognition, and communication technologies into a unified solution. Carts, connected in a continuous chain, feature belts aligned crosswise—hence "Cross Belt"—for item transport, loaded manually or automatically. At designated sorting stations, belts activate to ensure precise item placement.

Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments 0

Available in circular or linear configurations, these sorters offer exceptional performance. Circular models achieve 2 meters per second, sorting 22,000 items per hour, while linear designs reach 1.5 meters per second, handling 8,000 items hourly. Suited for high-throughput, multi-directional sorting, they're essential in express delivery, e-commerce, apparel, food, cosmetics, airports, and pharmaceuticals.

Technical Parameters
Equipment Name Circular Cross Belt Sorter Linear Cross Belt Sorter Linear Cross Belt Sorter
Model CBS-600C CBS-500L CBS-300L
Sorted Items Various parcels, cartons, clothing, books, etc.
Cart Pitch 600mm 500mm 300mm
Sorting Accuracy 99.99%
Sorting Efficiency 22,000 pcs/hour 6,000 pcs/hour 8,000 pcs/hour
Feeding Method Manual loading /Automatic loading from feeding station
Sorted Goods Size MAX: 700×600×500mm
MIN: 150×150×8mm
Scanning Method Top scan / Three-phase five-sided scan / Six-sided scan
Sorted Goods Weight 0.03kg ≤ W ≤ 20kg 0.03kg ≤ W ≤ 20kg 0.1kg ≤ W ≤ 30kg
Operating Speed 2.0m/s 1.5m/s 1.5m/s
Operating Noise ≤72dB(A)
Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments 1
Key Features
Mature and Reliable

The cross belt sorter excels at sorting small to medium parcels, accommodating a wide range of weights and volumes typical in express and e-commerce logistics. With multiple sorting chutes and stable performance, it's a proven, widely adopted solution in global logistics, backed by mature technology.

High Applicability

This system boasts robust stability and high capacity, making it versatile for sorting cartons, envelopes, clothing, plastic-wrapped goods, books, and media. Customizable equipment specs and chute sizes (e.g., 600mm, 700mm, 750mm, or 1000mm) adapt to site needs. Modular cart tracks allow flexible site integration, with adjustable chute quantities to meet unique demands.

Simple Loading Operations

Tailored to user workflows, the sorter supports manual loading or automated platforms for scanning, weighing, and loading. Basic training enables workers to operate it quickly, enhancing operational ease.

Modular Solutions

Standardized components and a lightweight design streamline production, transport, assembly, and commissioning, ensuring swift customer response. Modular setups simplify maintenance, boosting equipment uptime and efficiency.

Cost-Efficient Operations

High sorting efficiency reduces operator workload, optimizes staffing, cuts labor and management costs, and accelerates business growth with streamlined operations.

Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments 2
Industry Applications
Postal and Express Delivery

Cross belt sorters shine in regional centers, transfer hubs, and large postal or courier facilities with heavy sorting volumes. As labor costs rise, linear models are prized for compact, adaptable designs that enhance productivity.

E-Commerce and Global Trade

E-commerce peaks demand versatile sorting solutions. Cross belt sorters deliver, supporting industries like fashion, tobacco, baby goods, grocery, and pharmaceuticals with efficient processing.

Competitive Advantages
  • Intelligent Vision Systems: Realkey's sorters can integrate advanced vision technology for real-time cart monitoring, isolating faulty carts to prevent errors and issuing rapid alerts to minimize downtime (requires auto-feeding).
  • Enhanced Cart Linkage Technology: Realkey's algorithms optimize cart usage—single carts for small items, dual carts for parcels up to 1.2 meters—offering flexibility and efficiency without added costs.
  • Automated Maintenance Management: The interface allows carts to autonomously navigate to maintenance areas, reducing manual intervention and improving upkeep efficiency.
  • Proven Durability: With 18 years of logistics automation expertise, Realkey provides rugged, dependable sorting solutions, solidifying our status as a trusted industry partner.
Parcel Sorting Intelligent Loop Cross Belt Sorter With Advanced Software For Real Time Sorting Adjustments 3
